The IS2000 Software is a scalable windows application that was natively written for Windows 7/Vista/XP/2000/2003/2008. Due to its modular design, IS2000 can be customized to manage any size system, while offering a complete Security Management Solution that adheres to open architecture standards. IS2000′s built-in web server allows clients to access and control the system remotely via a web browser that is OS agnostic.

IS2000 uses ODBC to connect to different databases throughout the system. Information from these databases are downloaded to the field controllers, so that each controller can make decisions for all the devices connected to its sub-channels. The distributed intelligent network architecture allows all of the access control and security decisions to execute and record, even if communication is lost with the host computer.

IS2000′s open architecture and modular design allows the customer to expand the system based on the features and requirements of the site(s) being managed. The software has the ability to simultaneously manage traditional hardware platforms and newer web based IP controllers and readers from its seamless environment.

Below is a list of some of the basic modules offered in IS2000:

Access Control

Access Control The Access Control section of the software consists of a suite of modules that are used to control where and when a personnel record has access to a reader or group of readers. Modules consist of Personnel Manager, Access Levels, Time Schedules and Holidays.

Biometrics Biometric readers such as 3D Face Readers, Retinal Eye Scanners, Fingerprint Readers, etc… offer stronger user authentication with convenience. Unlike keys, cards, or number sequences, access through a biometric reader cannot be transferred, and requires that the person to be identified, to be physically present at the point-of-identification.

ID Badging This module comes with a Badge Designer which is an optional application that allows badge templates to be created. Templates created in the Badge Designer can be used in the Personnel Manager module of the IS2000 software, and link to the Personnel database.

Visitor Management The IS2000 Visitor Management Software Module is the most comprehensive visitor management system available. Allowing you to streamline registration, print professional visitor badges and view reports of all activities. With instant badge printing, self-registration option and automatic host notifications, the visitor management software is the top choice at organizations worldwide.

Reporting

Attendance Reporting The IS2000 Attendance Reporting Module provides accurate reports of employee hours for a specified date/time and area(s). These reports can be used in conjunction with payroll software and can auto-export to popular text file formats.

Report Manager The Report Manager is used to generate reports on the various databases of the system. Reports can be generated based on all regions or a selected region.

Email Reporting Emails can be sent to a single individual and/or groups of individuals based on any event/alarm in the system.

Guard Tour Manage tours and receive immediate notification when checkpoints are missed. Review reports and automate them to email based on pre-defined conditions. Completely integrated with IS2000 and supporting access control hardware platforms.

Graphics

Alarm Graphics Alarm Graphics will dynamically display real-time Alarms of the system. Operators can graphically zoom in and out of buildings and view real-time status of devices based on their floor plan positioning. Devices are plotted during the setup phase of the system, and will flash on the respective map when in an alarm state. The Alarm Graphics module of the software works in conjunction with the Alarm Manager which displays real-time alarms in a priority sorted list.

Graphic Maps Graphic Maps are used to graphically represent the facility or multiple facilities. This module allows the operator to graphically zoom in and out of buildings, view real-time status of devices, and control devices based on their floor plan positioning.

Integration Modules

Fire Alarm Annunciation The IS2000 software comes with drivers that will communicate and interface to a variety of UL Listed Fire Panels. Fire Events are integrated into the software’s Event/Alarm Manager modules, and can be used in conjunction with the Triggers and Macros for Integration.

Triggers and Macros The Triggers and Macros module allows the operator to program procedures to occur based on specific Events. A Trigger is defined as an Event that occurs in the system with specific properties. These Triggers are linked to execute Macros. A Macro is a command or a set of sequential commands put together.

Video Manager The Video Manager module is used to view real-time and recorded videos, allowing for customized views and multi-monitor support. It can also be used to program camera captions and set pre-alarm and post-alarm conditions.

The IS2000 Enterprise Video Manager provides a total integrated solution for digital surveillance and security applications that can be applied to tourist attractions, traffic monitoring, banks, campus environments, etc… All of our video solutions are scalable, starting with a single network video camera, to a DVR, to an enterprise based NVR. Flexible frame rates, bandwidth and quality allow users to adjust to various network environments.

The IS2000 software comes with drivers that will communicate and interface to a variety of IP Cameras, DVRs, NVRs and CCTV switchers. In addition the system will allow real-time/recorded video to be displayed in a sizeable window on the screen.

Cameras can be viewed graphically or based on device address. Camera commands such as pre-shot and video call-up can be designated as user-defined buttons or macros that execute based on specific conditions. Devices and events in the system can be associated to a camera, and based on the event/alarm the associated camera will auto display and/or do a quick record. Recorded video can be retrieved based on time/date selection and/or based on alarm/event reports.

• Video Manager Interface to manage multiple video systems
• Real-Time and Recorded Video Support
• Global Trigger/Macro Integration allows the video system to link to other systems in IS2000 (ex: Access Control System, Alarm System, HVAC System, other Video Systems, etc…)
• Hardware Manager Integration allows for programming and configuration of video devices and how they link to other devices in the system.
• Alarm/Event Manager Integration
• Plot Cameras to Graphic Maps for a convenient way to call-up video
• Reports that have associated recorded video can be easily queried and exported to a portable windows media format.
• Camera Control: Pan, Tilt, Zoom, Video Switch, Video Freeze, Tour Editing, Tour Resume, Monitor and Camera Caption Editing, System Reset, Time Set, etc…
• IPQ Technology allows for optimal performance regardless of the amount of camera input data
• IDP Technology allows easy integration and editing of high definition videos, images and audio data

INNOWATCH- Next Generation Control Room Solution

With increased awareness on security surveillance by corporate and individuals alike, market user demands have shifted from a mere passive monitoring solution to a more assertive and operative solution that integrates state of the art display technology with robust hardware for an effective control and monitor of dynamic activities involving high-resolution image processing, real-time video feed, various data and alert signals.

For a more customized build of the solution, next-generation control room solutions require a reinforced software structure that would effectively collaborate with control room hardware and enable easy-to-operate controls and monitors.

INNOWATCH provides the solution to such demands with a user-friendly interface that meets the every need of end-users and install technicians through simplified system integrations that minimize time and cost.

Powered by such core technologies, INNOWATCH is comprised of the following hardware and software components : iDISPLAY, iMERGER, iCONTROL, iVIDEO, iCONSOLE, iEDITOR.

SYSTEM OVERVIEW

As a next generation control room solution, INNOWATCH features the latest display technology through its innovative Intelligent Pixel Query (“IPQ”) and Intelligent Data Process (“IDP”) technologies.

IPQ technology intuitively and efficiently processes displayed camera images with optimal performance regardless of the amount of camera input data while cutting down on hardware and integration costs.

IDP technology allows easy integration and editing of high definition videos, images, and audio data, for an unsurpassed control in a Zoomable User Interface (ZUI) environment and enables easy-to-operate CCTV control room monitoring.
